Specification:

• Weight: 2.1kg (approx, including pole clamp)
• Dimensions: 307mm x 133mm x 128mm (not including pole clamp)
• AC Power Supply: 220-230V or 110-120V (not user adjustable) at 50-60Hz
• Battery Type: Rechargeable 12 V DC Nickel Metal Hydride Ni-MH
• Battery Life: 4 hours at 5ml/h
• KVO Rate: 0.5ml/hr (continuous mode, not VTBI)
• Infusion Rate Volume To Be Infused (VTBI): 0.1ml/h to 1200ml/h dependent on syringe size 0.1ml to 9999ml

OCCLUSION SENSING PRESSURE LEVELS: Approximate Pressure

• Low (L): 300mmHg ± 100mmHg 40.0kPa ± 13.3kPa
• Medium (C): 500mmHg ± 100mmHg 66.7kPa ± 13.3kPa
• High (H): 800mmHg± 100mmHg 106.7kPa ± 13.3kPa
• Drive Accuracy: ±2% (Linear Accuracy)

GRASEBYTM 2100 BODY WEIGHT MODE SPECIFICATIONS:

• Mass Units: mcg/kg/min or mg/kg/hr
• Body Weight: 0.1kg to 300kg
• Drug Mass: 0.1mg to 999.9mg
• Solution Volume: 0.1ml to 999.9ml
