Specification:

• Size: 18 x 6 x 22 cm (7.1 x 2.4 x 8.8 in) H x DXW
• Weight: Approximately 1.6 kg (3.5 lb) with battery and pads installed
• Therapy: Adult defibrillation: nominal peak current 32 A (150 J nominal into a 50-ohm load) Pediatric defibrillation with optional FRX Infant/Child Key installed: nominal peak current 19 A (50 J nominal into 50-ohm load)
• Waveform: Biphasic truncated exponential; waveform parameters are automatically adjusted as a function of patient defibrillation impedance
• Sealing: Waterjet-proof IPX5 per IEC60529
• Dust-protected IP5X per IEC60529
• Battery Item Standard: M5070A
• Capacity: When new, a minimum of 200 shocks or 4 hours of operating time at 25° C (77° F)
• Quick Shock: Able to deliver a shock after the last chest compression of a CPR interval, typically in 8 seconds
• Shock-to-shock cycle time: Typically less than 20 seconds between shocks in a series
