Display:

• Display Type: 7 inch high resolution LCD display
• Sweep Speed: 25mm/sec
• Information: HR. Lead/Pads, On/Off Alarm, SpO2, AED Functions and Prompts,
• Alarm Selection and Limits, Delivered Energy

Defibrillator

• Waveform: Biphasic
• Charge Time: Less than 7 seconds with a new fully charged battery.
• Energy Display: Monitor display indicates both selected and delivered energy.
• Charge Prompt Type: Voice and visual prompts.
• Electrode Impedance Measurement Range: 0-250 ohms.

ECG Monitoring

• Patient Connection: 5-lead ECG cable, or 3-lead ECG cable, paddles.
• ECG Size: 0.25, 0.5, 1, 1.5, 2, 4 cm/mV display on monitor.
• Heart Rate: 20-300BPM.

Sp02 Module(Optional)

• Measurement Range: 30- 100%, ± 2% between 80%-90%, others ± 5%

Recorder

• Paper: 50mm thermal.
• Speed: 12.5mm/sec, 25mm/sec, 50mm/sec. User-selectable 6-second delay.

Battery

• Type: Rechargeable, Ni-MH battery, 12V.
• Operating Time: For a new, fully charged battery: 60 defibrillator discharges at maximum energy, or 3 hours minimum of continuous ECG monitoring.

Manual Mode

• Energy Selection: Selectable at 2, 5, 7, 10, 20, 30, 50, 70, 100, 150, 200, 300, 360 joules.
• Synchronized Mode: Synchronizes defibrillator pulse to patient’s A-wave. “SYNC” message displayed on monitor
